SFX M3-M12 Pneumatic Tapping Machine for Machinery Manufacturing Industries

Product Parameters:

Model: PNEU-M12                    Main Motor Power: 600W

Working Precision: 0.05mm    Max. Stroke of Spindle: 1100mm

Main Declination: 90°              Max. Speed: 400rpm                Air Source: 0.6Mpa

Tapping Ability: M3-M12(Steel, Aluminum) M3-M8(Stainless Steel)

Range of Rotation: 400rpm(Stepless Speed Regulation)

Working Area: Horizontal Stretch 1100mm, Vertical Stretch 500mm(adjustable)

Features and Advantages:

1.Avoid the Limitations of Manual Tapping, Time-saving and Labor-saving, No Damage to Thread, and the Tap is not Easy to Break.

2.Easy to Operate, Fast Tapping with Two Buttons.

3.Overload Protection, Adjust the Torque, the Tap will Not Break.

4.Wide Range of Activities, Heavy Workpiece do not Need to be Moved.

5.Stable Performance, Sustainable Usage.

6.Smooth Running, Low Noise. High Strength Aluminum Alloy

7.Cantilever Double Gas Spring; Taiwan Air Motor; Taiwan Oil-water Separator

8.Standard Accessories: Upper and Lower Brackets of Articular; Extension Arm (One Set); Air Motor 400r/min (One Set); Tap Holder M3-M12 (One Set)

9.Optional Accessories: Universal Joint(Tapping for a Vertical/Horizontal); Magnetic Base Power 300KG (Tapping an Arbitrary Range); Moving Workbench

10.Applicable Materials: Copper, Iron, Aluminum, Steel, Stainless Steel, Plastic

11.Apply to all Machinery Manufacturing Industries, Mold/Plastic/Printing Machinery, Packaging Machinery Factories, Construction Machinery, Auto and Motorcycle Parts, Aero Engines, Rolling Stock and Other General Machinery Industries.
